liquid oxygen truck

Liquid oxygen truck mainly refers to the liquid oxygen transport vehicle under pressure. The tank structure is a double-layer structure. The body of the tank truck is composed of two major components: tank body and bottom frame. The tank body is a horizontal cylinder structure, which is equipped with a wave plate inside, which can reduce the inertia force during liquid transportation.

Design parameter table
Tank		Inner	Outer
	Working pressure (MPa)	1.6	vacuum
	Design pressure (MPa)	1.6	0.1
	Maximum allowable working pressure (MPa)	1.6	/
	Operating ambient temperature (℃)	- 183--144	- 40 ~ 50
	Operating temperature (℃)	- 40 ~ 50
	Geometric volume (m³)	26.5 (after reinforcement)	10.1 (Interlayer)
	Material	S30408	Q345R
Basic parameters of liquid oxygen truck	Overall dimension	12280×2510×3445
	Total load weight (kg)	40000
	Maintenance weight (kg)	12205
	Rated load weight (kg)	27795

Depending on the material, we have carbon steel/stainless steel/aluminum alloy tank semitrailers. We can also produce tank cars for various liquids, such as diesel, carbon dioxide, liquefied petroleum gas, liquefied natural gas, etc.

Pre-sale drawings can be designed according to your needs, after the deposit can be asked at any time offline or online video check product production status, after delivery can provide on-site installation and online installation guidance services, and there is a year of after-sales warranty service.
