The products are widely used in Metallurgy, steel structure, automobile manufacturing and other modern agriculture,they have the
advantage of compact structure, safe and reliable,convenient operation and maintenance.


|
Design Specification
|
||
|
Design Standard
|
GB150.1~GB150.4-2011 (Pressure vessel)
GB/T18442-2011 (Fixed vacuum insulated cryogenic pressure vessel) TSG 21-2016(Safety technical supervision regulations for stationary pressure vessels)
|
|
|
Model:CFL20/2.16
|
Inner Vessel
|
Outer Vessel
|
|
Medium
|
LCO2
|
Perlite
|
|
Working temperature:(°C)
|
-40~-18
|
Normally
|
|
Working Pressure:(Mpa)
|
2.16
|
-0.1
|
|
Minimum design metal temperature: (°C)
|
-40
|
-20
|
|
Design Pressure: (Mpa)
|
2.27
|
-0.1
|
|
Corrosion allowance:(mm)
|
0
|
1
|
|
Welding joint coefficient:
|
1
|
0.85
|
|
Material:
|
16MnDR
|
Q245R
|
|
Full Volume: (m³)
|
5.26
|
13.24
|
|
Effective Volume:(m³)
|
5
|
7.78
|
|
Air pressure test pressure
(MPa):
|
2.61
|
0.11
|
|
Vessel Thickness:(mm)
|
20
|
22
|
|
Head Thickness:(mm)
|
8
|
10
|
|
Dimensions:(mm)
|
5130*2000*2000(Can be customized)
|
|
|
Filling Rate:(%)
|
95%
|
|
|
Design life: (Years)
|
20
|
|
|
Tank empty weight:(kg)
|
4450
|
|
